Sea Jay 630 TROJAN HT

$0.00
* Sail Away
Send an Enquiry
630-Trojan-HT-10
630-Trojan-HT-12
630-Trojan-HT-17
630-Trojan-HT-261
630-Trojan-HT-31
630-Trojan-HT-409
630-Trojan-HT-5
630-trojan
DSC_59301000
Click to zoom / enlarge this image

Sea Jay Aluminium Boats have taken the cutting edge SAMURAI HULL to the next level with the TROJAN HT cabin boats are a true off-shore fishing craft with long range capabilities. The latest generation SAMURAI HULL has high tensile 5083 plate bottom and offers high swept bow section, reverse chines, capped keel. The variable dead-rise on a wide body configuration give optimum ride and performance with great stability at rest. The spacious lined cabin has loads of storage space for fishing and safety gear with V berth bunks to accommodate even the 6 footers.

Side Console

Steering

8.05 metres

Length

Aluminium

Hull Material

Mono

Hull Type

Details Specifications Features & Options
Boat Details
  • Make: Sea Jay
  • Name: 630 TROJAN HT
  • Model Number: 630 TROJAN HT
  • Year: 2025
  • Length: 8.05 metres
  • Width: 2.48 metres
  • Dry Weight: 1950 kg
  • Hull Material: Aluminium
  • Hull Type: Mono
  • Passenger Capacity: 6
  • Boat Usage: Fishing
  • Steering: Side Console
  • Warranty: 24 Months

SPECIFICATIONS 630 670
Bottoms (mm) 5.0 5.0
Plate sides (mm) 3.0 4.0
Transom (mm) 5.0 5.0
Beam (m) 2.48 2.48
Hull length overall (m) 6.59 6.90
Overall length approximate inc motor (down) & trailer (m) 8.05 8.20
Overall height approximate including trailer (m) 3.25 3.27
Bunk length (m) 1.8 1.8
Depth – internal floor to top of side deck (freeboard) (mm) 760 775
Depth – keel to top of hard top (m) 2.79 2.81
Number of persons (at 80kg per person) 6 6
Weight approximate – hull only standard boat (kg) 1100 1195
Weight approximate – standard boat (dry) / motor (230kg) / trailer (alloy agr6.5m-14the (kg) 1950 TBA
Maximum horsepower (hp) 200 225
Maximum motor weight (kg) 285 295

Specification subject to change without notice.

FEATURES 630 670
Anchorwell ✓ ✓
Anchorwell mounting plate to suit stress free anchor ✓ ✓
Plumbed live bait tank ✓ ✓
Bait board Deluxe. includes 4 x alloy rod holders, 5 utility slots, 2 drink holders, 2 knife slots, drawer & removable cutting board. (Some engines may need trim limit switch) ✓ ✓
Tackle storage in transom to suit 5 x 237002 series plano tackle trays ✓ ✓
Dual Battery pre-rig – in transom ✓ ✓
Bollards – 1 x front, 2 x rear ✓ ✓
Bow sprit to suit sarca anchor ✓ ✓
Bungs – alloy 38mm 1 1
Checker plate drop down foot well (drained) ✓ ✓
Cabin storage – under bunks ✓ ✓
Cabin hatch with support stay ✓ ✓
Floor – 3mm checker plate wash down alloy floor with sump box ✓ ✓
Floatation – foam ✓ ✓
Foot rests – driver & passenger side ✓ ✓
Hard top – alloy ✓ ✓
Instrumentation dash ✓ ✓
Overhead radio console ✓ ✓
Reverse chine hull ✓ ✓
Side pockets (extra long) 2 2
Spray deflector strake ✓ ✓
Steering assembly cover ✓ ✓
Towing eye (double) – heavy duty ✓ ✓
Transducer brackets 2 2
Trim tab brackets 2 2
Transom boarding platform – non skid ✓ ✓
Wide side decks ✓ ✓
STANDARD FIT OUT INCLUSIONS
Checker plate main floor ✓ ✓
Dive door ✓ ✓
Heavy duty ladder ✓ ✓
Sump box with bilge pump and alloy bung with drain overboard ✓ ✓
Kill tank self flooding ✓ ✓
Hood lining – cabin (roof & sides) ✓ ✓
Inspection port x 1 (in cockpit floor) ✓ ✓
Non skid top deck ✓ ✓
Paint – white / fleck (2 pac commercial marine grade) ✓ ✓
Pin stripping ✓ ✓
Rod holders (alloy) x 6 – in wide side decks ✓ ✓
Rocket launcher with 8 x alloy rod holders ✓ ✓
Glass windscreen 3 piece ✓ ✓
Sliding windows 2 2
Plate style electric trim tabs ✓ ✓
ELECTRICAL
Accessory pre rig loom – to suit dual battery ✓ ✓
GME gx700 VHF radio flush mounted with 1.8m aerial ✓ ✓
Battery storage (large) x 2 ✓ ✓
Battery master / isolation switch (BEP) dual ✓ ✓
Bilge pump ✓ ✓
Bilge pump sump box ✓ ✓
Light (led) – cabin x 1 ✓ ✓
Light (led) – underside of hardtop x 1 ✓ ✓
Light (led) – anchor folding (on hard top) ✓ ✓
Light (led) – navigation ✓ ✓
Power socket 12v with USB ✓ ✓
Switch panel 4 gang 2 2
6 gang fuse panel (5 spare circuits) ✓ ✓
FUEL TANK
Under floor / gunwale filler (litres) 210 270
Fuel hose cover ✓ ✓
Fuel sender ✓ ✓
RAILS
Bow (32mm) ✓ ✓
Transom (32mm) ✓ ✓
Grab handles – around hard top ✓ ✓
SEATS
Offshore bucket bolster seats ✓ ✓
Drivers side seat box with tackle storage to suit 6 x plano 4-3730-0 tackle trays ✓ ✓
Passenger side seat box with storage hatch & shelf ✓ ✓
Seat slide and swivel – driver – passenger swivel only ✓ ✓
STEERING
Hydraulic steering ✓ ✓
Sports steering wheel ✓ ✓
TRANSOM
Ultimate Edge 2  –  25” ✓ ✓

Features subject to change without notice

OPTIONS
 630 670
Bunk in fill (centre) opt opt
Cabin bunk cushions (3” foam) 4 piece opt opt
Carpet on inside of cabin walls opt opt
120 Watt Solar System opt opt
Coloured sides (white or pipeline greay as standard) opt opt
Minn Kota 112lb 36v opt opt
Modify rails & cabin to fit 72″ 36v self deploy Minn Kota (Includes extended Minn Kota plate & battery storage area in place of flooding kill tank. Boat persons capacity may be reduced by 1 opt opt
WINCH – Stress Free NG Midi Fitted Inc 70 m of 8mm nylon spliced with 6 meters of short link chain opt opt
1/2 rear lounge & back rest opt opt
Salt water deck wash kit opt opt
Sarca # 2 anchor with s/s swivel opt opt
Printed vinyl wrap opt opt
Upgrade to 4mm sides opt opt
Windscreen wiper with washer opt opt
Starboard side drivers box seat with fridge slider to suit 40ltr Engel opt opt
Trailer – Galv Steel. Get Extra 12 Month Warranty – Free * opt opt
Trailer –  Alloy. Get Extra 12 Month Warranty – Free * opt opt
Spare Wheel Kit opt opt

* Extra 12 month warranty applies if Sea Jay Boat is bought with a Sea Jay trailer
Options subject to change without notice
